Coin Cell Hydraulic Crimping Machine

Coin Cell Puncher: punching diameter can be customized according to your requirements, for button battery cell, we often use 14 15 16 18 19 20 mm diameter model. Can be used for battery coated electrode, copper foil, Aluminum Foil and battery separator cutting to round pieces Disc cutter features: one-time cutting, no burrs, smooth edges

This vacuum mixer is vacuum mixing, dispersion efficient equipment, it is suitable for battery electrode paste and various ceramic materials mixing, due to complete the process in vacuum station, fully implemented without air bubbles, improve the filling material and density

MT-SHYT-1200X is a single zone rotary tube furnace is designed for calcining inorganic compound with better uniformity, especially excellent for preparing Li-Ion battery cathode materials with conductive or protective coating on powder, such as LiFePO3, LiMnNiO3, etc in R&D Laboratory.

Planetary ball mill is necessary equipment for mixing, fine grinding, sample preparing, nano-materials dispersing, new product developing and preparing small volume high-tech material production.

It uses a floating piston design with no seals to wear or replace, minimizing service downtime. Dispenser is accurate to 0.5% with coefficients of variation of 0.1%. Digital models feature accurate and reproducible volume settings via a mechanical digital display.

MT-XJB-500 Planetary vacuum mixer is one high efficiency equipment with vacuum molding and dispersion function, suitable for the battery lab research of anode and cathode electrode slurry mixing process, as well as for the powdered and ceramic material materials mixing. Due to the fact that the stirring is completed in the vacuum state, there’s without air bubble, to improve material fillibility and model compactness and the compactness of model are improved. This Equipment can be used for Coin, Pouch and Cylindrical Cell all format in R&D level.

New upgrade: Faster sealing speed and less noise.This electric coin cell crimping machine mainly use for laboratory battery material research, it can be also used for small scale button battery production in factory. It is equipped with electric driver, compare with hydraulic type, it is labor-saving. You can also change the die for dry powder tablets, wet powder tablets, press molding, riveting and other operations.

The Coin cell disc cutter machine is used for coin cell electrode punching with customized cutting die. Its operation is simple with light weight; The resulting discs can be used as electrode/separator discs of split test cell and coin cell for battery researches.

Vacuum drying oven is a kind of laboratory equipment for drying and heating treatment under vacuum environment, specially designed for drying heat-sensitive, easy to decompose and easy to oxidize substances, when working, it can keep a certain degree of vacuum in the working chamber, especially some items with complex composition can also be dried quickly.

Can be used for a variety of chemical, biological, pharmaceutical, medical, agricultural research, environmental testing and other fields, powder, easily oxidizable substances, need to be dried in vacuum, baking, sanitize, test and so on

This slurry filter is mainly applied to a special filter designed for laboratory samples to filter out various hard particles with a particle size of not less than 124 microns in the slurry. The whole machine has beautiful design and is flexible and convenient to use.

This Machine Can be used for Both Coin and Pouch Cell R&D level

MT-DG-150L Lab Roll Press Machine is a compact precision electric rolling press machine. It has dual rollers of 96 mm dia. x 150mm width and dual grade micrometre. This lab roll press machine is an ideal rolling press for adjusting thickness and increasing active material density of the electrode in Li-Ion batteries research after coating and drying.

This hand-held disc punching tool is designed for coin cell electrode and separator preparation. It includes five dies, ID 8, 12, 15, 18 and 20 mm. It is an excellent and cost-effective tool for cutting round electrode disc up to 0.3 mm thickness. It can be used to cut separators and electrode material-coated Al and Cu foils.

Since the viscosity of battery electrode pasta/slurry plays an important role during the electrode coating on current collector, it is necessary to use a tester to monitor and then adjust the viscosity when mixing. Usually, the cathode slurry viscosity needs to be controlled in range of 6000-1000cp, and Anode slurry viscosity needs to be controlled in range of 1000-3000cp. MT-NDJ-5S Digital viscometer is with viscosity testing range from 10-100000cp, it can display the testing result in the screen directly without calculate. It is ideal viscosity testing equipment for lithium battery producing and lab research.
