Desktop Coating Machine with Dryer for Pouch Cell

This device is mainly applied to flexible packaging (medium and small size) lithium battery in the injection of liquid after standing vacuum, hot compression package; simple secondary packaging.

200*200mm Size Hot Press Machine for Lithium Battery Cells After Winding Process

Ultrasonic metal spot welding machine for lithium ion batteries is a special device used in the manufacturing process to perform spot welding. It uses ultrasonic technology to weld two metal sheets together, forming the electrodes of the battery.

Mainly used in heating type sealing equipment on the top and side of soft packaging lithium-ion batteries. The device uses resistance heating to seal the head, so that the aluminum-plastic film can be melted under a set pressure.

Battery stacking machine is a semi-automatic stacking machine. It is an ideal tool for stacking multiple layers of positive & negative electrode and separator for pouch cell. The battery stacking machine is used for lithium battery stacking process, put the cathode, anode electrode and battery separator Z-shaped lamination.

Battery Pouch Forming Machine is used for lithium polymer battery/ pouch cell cup forming in the production line of making pouch cell batteries.

MT-MQ300 semi-automatic electrode die cutter is mainly used for pouch cell electrode sheet cut for stacking pouch cell battery. It is a necessary tool in the production line of pouch cell to produce specific shapes of cathodes and anodes with current collector tabs. This Semi-Automatic Die Cutting machine adopts Safety Curtain built in the front of the machine and double start button ensures operation safety when electrode sheets are fed from the front. High speed, high accuracy, long lifetime to make cutted electrode without burr, to get a good consistency. This model has max die dimension with 200*300mm, if need other models, please choose the MT-JD-500model with max die size up to 500*500mm.

This product is suitable for die-cutting and forming of battery positive and negative plates, as well as for die-cutting of lithium plates.

MT-MCP85 pneumatic die cutter is suitable for die-cutting of positive and negative electrodes of batteries, punching sheet type electrode by pneumatic method and can be placed in the glove box.

This equipment is mainly suitable for vacuum hot sealing of pouch cell after electrolyte filling and standing; the machine can automatically complete vacuum thermal sealing of aluminum laminated film by precisely controlling the main vacuum pumping box and pneumatic heat sealing components.

Planetary ball mill is necessary equipment for mixing, fine grinding, sample preparing, nano-materials dispersing, new product developing and preparing small volume high-tech material production.

MT-XJB-500 Planetary vacuum mixer is one high efficiency equipment with vacuum molding and dispersion function, suitable for the battery lab research of anode and cathode electrode slurry mixing process, as well as for the powdered and ceramic material materials mixing. Due to the fact that the stirring is completed in the vacuum state, there’s without air bubble, to improve material fillibility and model compactness and the compactness of model are improved. This Equipment can be used for Coin, Pouch and Cylindrical Cell all format in R&D level.

Can be used for a variety of chemical, biological, pharmaceutical, medical, agricultural research, environmental testing and other fields, powder, easily oxidizable substances, need to be dried in vacuum, baking, sanitize, test and so on

This slurry filter is mainly applied to a special filter designed for laboratory samples to filter out various hard particles with a particle size of not less than 124 microns in the slurry. The whole machine has beautiful design and is flexible and convenient to use.

MT-DG-150L Lab Roll Press Machine is a compact precision electric rolling press machine. It has dual rollers of 96 mm dia. x 150mm width and dual grade micrometre. This lab roll press machine is an ideal rolling press for adjusting thickness and increasing active material density of the electrode in Li-Ion batteries research after coating and drying.

Since the viscosity of battery electrode pasta/slurry plays an important role during the electrode coating on current collector, it is necessary to use a tester to monitor and then adjust the viscosity when mixing. Usually, the cathode slurry viscosity needs to be controlled in range of 6000-1000cp, and Anode slurry viscosity needs to be controlled in range of 1000-3000cp. MT-NDJ-5S Digital viscometer is with viscosity testing range from 10-100000cp, it can display the testing result in the screen directly without calculate. It is ideal viscosity testing equipment for lithium battery producing and lab research.
