Laboratory Intermittent Coating Machine

Automatic battery electrode coating machine with a compact footprint that is less than 6'x3'. It uses transfer coating technique for better coating uniformity and is perfect for research or building prototypes (e.g. pilot scale studies) of new generation rechargeable batteries. It is integrated with the functions/ features of metallic foil roll unwinding (reeling out), slurry feeder, coating blade, baking oven, and final electrode winding (reeling in) together with touch screen operation for customer's the most convenience.

No items found.

Technical Specification:
Working Voltage  380V AC
Max. Power Consumption  10 KW (30A Air breaker required)
Max. Coating Width  300mm
Thickness adjustable range  0-5mm
Coating thickness (after drying)

20 - 200um (for most kinds of battery electrode coating material)
Note: The dried coating thickness results vary depending on the physical property of the coating material.
Thickness Precision  ± 3µm (± 5µm at edges)
Coating Speed  0-300 mm / minute 
Max. Drying Temperature   150°C
Temperature Accuracy  ±2.5°C
Heating Zone Length  710mm (28")
Reeling/Unreeling Shaft  75mm (ID)
Max. Reeling/Unreeling Diameter  300mm (OD)

Max. Coating Length

·Depending on the coating and substrate thickness.

·Typically, 10um thick foil with 100um coating can get 600 meters of electrode length coated per run
Coating Modes

·Using transfer coating technique (Reverse comma) for better uniformity 

·Intermittent coating (system performs coating, stops, coats again and so on. The length of the coating and break segments can be specified by the user).

·Two available coating modes selectable on the control panel.
Slurry Stirring  SS316 Moving Rod
Exhaust Port Size  127mm OD
Compressed Air  0.5-0.8 MPa (Air compressor not included. Please click here to order)
Product Dimensions  1650mm (L) x 1250mm (W) x 1200mm (H)
Warranty

· Two Years limited warranty with lifetime support

· Rusting and damage due to improper storage condition or maintenance are not covered by warranty
Net Weight  1000 kg 
Shipping Dimension  70" x 50" x 60"

‍

Download detailed product technical specifications for more details

Download Specifications
