Ultrasonic Metal Welding Machine

MT-VS-40A is a CE Certified ultrasonic metal welder with touch-screen controller. It is designed for welding stacked electrode foils/sheets and tabs onto current collectors to prepare Li-ion pouch cells & cylindrical cells. The 2000w battery welder can weld stacked electrode with 10-35 layers aluminum foil or copper foil with Al tab and Nickel tab.

No items found.

Note: If you are not quite clear about what welder would be suitable for you, please consult the sales manager with following parameters, they will find a solution for you:

1. Weld material
2. Thickness of the material
3. Layer number of material


Features  Preset welding programs selectable for Al and Cu (Note: Welding power can be readjusted to fit the needs for welding other types of metals such as Au, Fe, Ni, Ag...).
Input Voltage  AC 110V or 220V +/-10%, 50/60Hz
Max. Power Consumption  2000W (can be customized)
Welding Area  4mm(L) x 4mm(W) (can be customized)
Welding Head  The welding heads and welding base are included for welding both aluminum & copper current collectors from 2 to 25 layers
Ultrasonic Frequency  40K Hz (can be customized)
Product Dimensions

1.     Controller: 360mm(L) x 480mm(W) x 200mm(H)

2.     Welder: 200mm(L) x 460mm(W) x 270mm(H)
Net Weight  70kg
Compliance  CE Certificate
Warranty  One Year limited warranty with lifetime support

‍

Download detailed product technical specifications for more details

Download Specifications
